ChemoPADPLStraining2026_Annotated Dataset

The annotated successor to the Lieberman-Lab_ChemoPADNNtraining2024_Partial-Drug-Set_v1.0 release. The project label is updated to ChemoPADPLStraining2026 because (a) the predominant downstream method on this corpus has been per-drug PLS concentration regression and PLS-DA classification, with neural-network experiments filed as comparison points rather than the primary modelling line, and (b) the annotation pass and HPLC re-labelling completed in 2026. This version is a hand-curated extension of the original ChemoPAD corpus and ships HPLC-measured concentration labels alongside annotation-specific quality flags (Lighting, Background, upstream status, missing_card).

Description

This dataset consists of 3279 card images from 646 unique samples (PAD#s), split deterministically by PAD# into development, validation, and test sets so that no card is shared between splits. The Active Pharmaceutical Ingredients (APIs) cover eight chemotherapy drugs plus Lactose and Blank, at continuous concentrations measured by HPLC (not the nominal 33 / 66 / 100 % buckets of the prior release).

Data Distribution

Split	Images	Unique PAD#s
Development (train)	1990	395
Validation	818	158
Test	471	93
Total	3279	646

Class Distribution

	class	#dev	#val	#test	#total
0	mesna	368	149	93	610
1	hydroxyurea	365	147	94	606
2	doxorubicin	335	142	71	548
3	cisplatin	313	132	71	516
4	mtx-oral	170	68	42	280
5	oxaliplatin-2-mg-ml	153	63	37	253
6	oxaliplatin-5-mg-ml	128	53	30	211
7	mtx-injectable	124	53	28	205
8	lactose	29	11	5	45
9	blank	5	0	0	5
-	#total	1990	818	471	3279

Dataset Visualizations

Class Distribution by Split

Upstream Camera × Drug

Coverage gap visible: HMD Global Nokia 2.3 only carries Hydroxyurea (and a small Mesna slice), so any per-Nokia analysis is constrained to those two drugs. unknown is the bucket for the Methotrexate variants. iPad and Pixel 3a cover the rest.

Lighting × Drug (annotation column)

Lighting (lightbox, benchtop, no light) is balanced for the four largest drug classes; lower-count drugs still have all three lightings represented.

Background × Drug (annotation column)

Background (black, white) is imbalanced for several drugs: Cisplatin and Mesna lean white; Oxaliplatin 5 mg/mL leans slightly black. Useful for stratified evaluations.

What’s annotated

Each row carries the standard registry columns (id, sample_id, sample_name, quantity, camera_type_1, url, hashlib_md5, image_name) plus five extended columns that are the value proposition of this release:

Column	Values	Source
camera_bucket	ipad, pixel, nokia	analyst-merged 3-bucket relabel of the upstream camera_type_1
lighting	lightbox, benchtop, no light	annotator-recorded capture lighting
background	black, white	annotator-recorded background colour
status	valid, invalid	joined from upstream unmatched_cards_export.csv
missing_card	True, False	annotator flag for cards the analyst could not visually review

Strict-schema consumers ignore unknown columns; tools that know them can use them as capture-condition covariates or quality filters.

What changed vs the prior Partial-Drug-Set_v1.0 release

• +1,206 unique cards added (3,714 vs 2,847) and +154 unique PAD#s (646 vs 492) through the annotation effort.
• HPLC-measured concentrations. The quantity column carries HPLC ground-truth concentrations (rescaled per API to % of nominal strength). See the per-API scale-factor audit at data/HPLC/per_api_scale_factors.csv in the source repo for the derivation.
• PAD#-grouped split discipline. The deterministic 60 / 25 / 15 train / val / test split groups by physical card (PAD#); no card leaks across splits.
• Camera bucketing. Upstream camera strings are merged into three buckets (ipad, pixel, nokia) by the analyst; the raw upstream string is preserved in camera_type_1.
• Explicit quality flags (status, missing_card) and capture-condition covariates (lighting, background) for stratified evaluations.

Source manifest

data/splits/manifest.csv (md5 6da9b45dae27fd75e278adbaa608e808) is the authoritative input. The deterministic split is reproducible.

Directory Structure

datasets/Lieberman-Lab_ChemoPADPLStraining2026_Annotated_v1.0/
├── README.md
├── class_distribution.csv
├── croissant.jsonld
├── dataset_sizes.md
├── figs/
│   ├── class_distribution.png
│   ├── camera_drug_heatmap.png
│   ├── lighting_drug_heatmap.png
│   └── background_drug_heatmap.png
├── labels.csv
├── metadata_dev.csv
├── metadata_test.csv
├── metadata_val.csv
└── projects.csv

Citation

If you use this dataset, please cite:

Wilfinger, M., Moreira, P., Mike, M., Sweet, C. Annotated ChemoPAD NN Training Dataset, v1.0. Lieberman Lab, University of Notre Dame. https://github.com/PaperAnalyticalDeviceND/annotated_chemopad

Annotation tool

The hand-annotation pass was carried out using Priscila Moreira’s PAD annotation web tool: source at github.com/PaperAnalyticalDeviceND/chemo-pad-annotations, deployed instance at http://pad-annotation.crc.nd.edu:8080. The tool’s controlled vocabulary is what defines the lighting, background, status, missing_card, and camera_bucket value sets in the metadata CSVs above. See the source-repo wiki page Annotation-Process for the per-card workflow.

License

Apache License 2.0 (consistent with the parent registry).
